Kit Absolute Encoders
US Digital designs and manufactures absolute encoders in optical configurations for the highest possible resolution and accuracy and magnetic versions for demanding environments. In either case, absolute encoders report a shaft angle within a single 360-degree shaft rotation without stops or gaps. Unlike incremental (sometimes called relative) encoders, absolute encoders provide true (absolute) shaft position, eliminating the need for a home or zero cycle after a supply voltage power cycle.
Showing All Kit Absolute Encoders
A2K Absolute Optical Encoder: Kit Version
- Installs onto shafts up to 10mm diameter
- 12-bit resolution, and resolution field programmable from 2 to 4,096 codes per revolution (3,600 factory default)
- Full 360 degrees range, 7 msec update time
- Low power drain of 18.5 mA max., and 2.5 mA in sleep mode ...
More A2K Details
